KH3351 Smart Differential Pressure Transmitter
KH3351 is a multi function smart digital pressure transmitter for industrial d ifferential, gauge and absolute pressure measured for gas, liquid, vapor, widely ap∏plied in petroleum, metallurgy, chemicals, power, light industry, mechanica₹l and environmental protection fields;
well-designed and developed by our own based on our years of rich industrial manufactu₽ring experience, based on adopting modern advanced, mature and reliable capacitive sensor λtechnology, combining with advanced single-chip computer teπchnology and sensor digital conversion technology.
CPU adopts sixteen single chips with powerful featur≠es and high-speed match ability guaranteeing the transmitte&r in good quality and performance; its software using digital signal processing techn ology making it with excellent anti-interference ability and zero stability and zero automatic stable tracking ability (ZSC) and automatic temperature compen≥sation ability (TSC).
Powerful screen features not needing hand held communicat§or can guarantee good interaction. LCD indicator can d→isplay digital pressure, temperature, current value and 0-100% analog indication. In case of non-standard pressure source, zero shifts, range setting, d¥amping adjustment etc basic parameters can be set through key button; and also making re-calibr∏ation on the transmitter, greatly convenient for on-site calibra✔tion.
Serial communication interface can convert signal to 4-20mADC output by specified converter mo€dule, also can achieve remote transmission setting and monitoring through Hart protocol (RS485 module) to set and monitor remote transmi•ssion, directly connecting with the master, such as paperless recorder, controller, ind♥icator etc instrument, HMI, IPC, PC, and Industrial Lan.
---Accuracy：Measured accuracy: ±0.2% to±0.25% FS，
Digital →
---Stability : 5 years of 0.25%
---Power supply: 12V to 45VDC, 24VDC default
---Range:-100Pa to 40Mpa, Range ratio: 1:1
---Linear output: 0.075%±0.1%, range ratio:1:1
---Turn on time :≥0.2second
---Damping adjustment :0-32 second
---Fill Fluid : Sillicon/ Fluorine Oil
---Vibration Effect :±0.05% of URL per g toβ 200 in any axis
---Output Signal:4-20mA current output
HART( RS485 port with communication keyb®oard, without
hand held communicator)
---Power Connection: cable, air plug, Hirschman plug---Process Connections: 1/2NPTφ, 1/4NPT &✔nbsp;
---Material:
Drains/Vents: Stainless Steel 316/
Monel/ Hastelloy
Diagrams: Stainless Steel 316L/
Monel/Hastelloy C/Tantalum
Wetted O-Ring : Viton/ Buna-N
Seal O-Ring : Viton/ Buna-N
Bolts&Nuts : Carton Steel/Stainless Steel316
Flange/Adaptor: Stainless Steel 316L/
Monel/ Hastelloy/Carton Steel
Converter house: Low copper cast aluminum alloy with
Polyurethane paint
---Enclosure: IP67 (Standard)
&nb&sp; : Intrinsically Safe EEx ia IIC T5
&nb"sp; : Explosion proof Ex D IIC T5
---Protection Class: IP67
---Weight: 2.7KG
---Ambient temperature:
-40℃ to 85℃
---Ambient Humidity:
0-95%RH
---Humidity limits:
0-100%RH relative humidity
