KH300GF Mini Color Paperless Recorder

KH300GF is high quality lost cost mini color paperless recorder (72x72x1"10mm, up to 4 channels), used the advanced technology≈, to be designed high quality and performance, isolated, high accurac↑y, universal use, to be aimed to monitor, record, analysis the processes i✔n various industry application


introduction

KH300GF mini color paperless recorder (72x72x110mm, up to 4 channels) is TFT true color LCD display; completely isolated universal input such as  thermocouple, thermal resistance, current and voltage, adopts modu←lar structure output functions such as alarm, auxiliary power supply &♦nbsp; for sensors output, retransmission, print and communication etc. Measuring data can b→e displayed in various types, such as graphic display as bar-graph, real-time trendin&g, history trending memory, real time circular chart, history circular chart memory and alar€ming state display; also can be printed in curve and data by mini printδer through RS232 port. At the same time, it also provides features to check the data∑’s of year, month, day, hour, minute, second directly. Recorder can be configuration₩ with OPC server, SCADA system and other professional software with MODBU§S-RTU communication protocol through RS485 port. The history data can₹ be downloaded directly by USB flash drive, plug and play, easy and flexible. PC supported data anγalysis software can print the data in curve and output Excel format for fuεrther analysis.

specifation

--Accuracy: ± (0.2%FS+1）digit
---Power Supply:100-240VAC; 24VDC
---Display: 2.4 inch , 320*240 TFT color LCD
---Input Signal
    T.C: K, S, E, J, T, B, N, R, WRe526, WRe 325
    RTD: PT100, CU50, CU100
    Linear voltage: 0-5V, 1-5V, 0-10→v
    Linear current: 0-10mA, 4-20Ma
    Specials: 0-20mV, 0-60mV, 0-100mV, 0-500mV
---Output Module
    Relay alarm output
    4-20mA Retransmission output
    RS485, RS232 Communication port
    24VDC Aux. Power Supply output
    RS232 Printing port
    USB Port
---Record time
    Flexibly setting interval time: 1s, 2s, 3s, 4s….3600s
    Record Time:
         ≤   45days x Record interval time
          ↓;       Channel numb★ers
    Screensaver Protection
    Screensaver time setting for LCD background light auto off
    when no any operation in order to decre©ase the power
    consumption.
---Power-off Protection Time
    The setting parameters and history data can be ​kept
    by FLASH  MEMORY, memorized forever i≥f power off.
    Hardware clock built in for still accuracy running.
---Environmental temperature:
    0-50℃
---Environmental humidity:
    0-85%RH

E.g. Order Code: KH304GF-R2A-R2C-S1-U-NNN, model: KH300GF, 72x72x110mm, 4 Channels input, 2 relay output, RS485 communication port∞, USB transfer, 100-240VAC power supply.
